M3 Mobile OX10 User Manual

Application usage
27
3. Application usage
3.1 Bluetooth
3.1.1 Bluetooth configuration
Turning on
Click on Bluetooth icon on task bar ( ) and choose ‘Enable Bluetooth’ to turn
on the Bluetooth module. Once the Bluetooth is on, the task bar icon will change to
to indicate it is enabled.
To turn it off, simply disable the Bluetooth after click on icon from task bar.
M3 ORANGE can use two different Bluetooth stacks:
1. StoneStreetOne (default)
2. Microsoft
Bluetooth stack can be changed from
StartSettingsSystemBT Select
The device must go through power cycle after stack change.
3.1.2 Getting connected
Set Bluetooth Connection
Bluetooth connections can be configured using BTExplorer. To launch BTExplorer,
click on Bluetooth icon on task bar ( ) and choose ‘Show BTExplorer’.

M3 Mobile OX10 Specifications

General

Display diagonal	3.5 \
Display resolution	480 x 640 pixels
ROM capacity	1000 MB
Internal memory	0.256 GB
Internal memory type	RAM
Compatible memory cards	MicroSD (TransFlash)
Maximum memory card size	32 GB
Processor family	-
Processor frequency	0.833 GHz
Data network	EDGE, GPRS, GSM, HSPA+, UMTS
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
GSM bands supported	850, 900, 1800, 1900 MHz
Security algorithms	AES, CCX v4, EAP-FAST, EAP-TLS, EAP-TTLS, LEAP, TKIP, WEP, WPA, WPA2
WCDMA bands supported	800, 850, 1900, 2100 MHz
Rear camera resolution (numeric)	3.2 MP
Storage temperature (T-T)	-20 - 50 °C
Operating temperature (T-T)	-30 - 70 °C
Battery capacity	3300 mAh
Product color	Black, Orange
Keyboard layout	Alphanumeric
International Protection (IP) code	IP65
Operating system installed	Windows CE 6.0

Weight and Dimensions

Depth	24.9 mm
Width	78.6 mm
Height	165.5 mm
Weight	332 g
