SECTION 4. TROUBLE SHOOTING
Adjust1)Lengths of RH and LH tie-rods are different
● Different steering angles in both directions
Tighten correctly to specified torque
Replace
Replace
Lubricate or replace
Adjust
1)Loose fasteners
2)Worn or damaged final case bearing
3)Worn bush
4)Wear or poor movement of tie-rod end
5)Excessive backlash of differential and bevel gear
● Noise
Adjust
Replace
Readjust correctly:2-6mm
(0.08-0.24 in)
Engage FWD only when required
1)Improper tire inflation
2)Worn front wheel shaft bearing
3)Poorly adjusted toe-in
4)Front wheel drive is always engaged
● Excessive or eccentric wear of tire
Replace
Adjust inflation or replace
Replace
1) Deflected wear of tire
2)Different tire diameters
3)Damaged final case bearing
● Steering wheel tends to turn to the right or left while traveling on straight paved road.
Adjust balance
Repair or replace
Adjust inflation or replace
Repair or replace
Retighten or replace
Replace
Retighten
Retighten
1)Unbalanced wheels
2)Wheel deflation
3)Unequal diameter of both tires
4)Loose,worn,or damaged wheel axle bearing
5)Loose,worn,or damaged wheel steering wheel shaft
6)Worn final case bush
7)Loose final case-front axle tightening bolt
8)Loose front wheel(tire)tightening nuts1)
● Vibrating or pulling steering wheel
Inflate to specified value
Replace
Grease or replace
Grease or replace
1)Too low tire inflation
2)Broken thrust bearing
3)Stuck or broken ball joint of tire-rod end
4)Seizure or poor lubrication of axle end bush
● Steering wheel hard to turn
COUNTERMEASURESPROBLEMS AND PROBABLE CAUSES
