Makita DTD152 Technical Information

July 2015
2. ABOUT THIS MANUAL
The number in the parenthesis () is the item number on the exploded diagram (Figure 1).
3. REPAIR
Repair the machine in accordance with “Instruction manual” or “Safety instructions”.
3.1. NECESSARY REPAIRING TOOLS
Code No. Description Use for
1R003 Retaining ring pliers ST-2N removing Ring spring 11 (8)
1R040 Armature holder 50 set for use with Vise removing / assembling Hammer case complete (13)
1R045 Gear extractor (large) disassembling Hammer section (17-25)
1R212-A Tip for retaining ring pliers use with 1R003 in order to remove/ assemble Ring spring 11 (8)
1R212-B Plate set (with screws)
1R223 Torque wrench shaft 20-90N
·
m assembling Hammer case complete (13)
1R224 Ratchet head 12.7 attaching to 1R223, when assembling Hammer case complete (13)
1R232 Pipe 30 removing Bit sleeve (11)
1R288 Screwdriver magnetizer removing Steel balls
- Socket 30-78 use with 1R223 and Extension bar in order to remove/ assemble
Hammer case section (8-28)
- Socket 32-50 removing/ assembling Hammer case section (8-28)
- Extension bar (Square drive: 12.7 mm) removing Hammer case section (8-28)
5 / 27

Makita DTD152 Specifications

General

Power source	Battery
Battery voltage	18 V
Battery level indicator	Yes
Product color	Black, Blue
Idle speed (max)	3500 RPM
Screw diameter (max)	16 mm
Maximum torque (hard applications)	165 N⋅m
Vibration emission	10.5 m/s²

Weight and Dimensions

Depth	137 mm
Width	79 mm
Height	238 mm
Weight	1500 g
