Manitowoc Indigo ID0502A User Manual

126 Part Number STH025 11/16
SYMPTOM #2  FREEZE CYCLE REFRIGERATION SYSTEM OPERATIONAL ANALYSIS TABLES
SINGLE EVAPORATOR, SINGLE EXPANSION VALVE
SELF CONTAINED AIR, WATER & REMOTE CONDENSER
Operational Analysis 1 2 3 4
Ice Production Reference “Ice Production Check” on page 133
Air-Temperature Entering Condenser ______________ Water Temperature Entering Ice Machine ___________ Published 24 hour ice production _________________ Calculated (actual) ice production _________________
NOTE: The ice machine is operating properly if the ice fill patterns is normal and ice production is within 10%
of charted capacity.
Installation and Water System Reference “Water System Checklist” on page 136
All installation and water related problems must be corrected before proceeding with chart.
Ice Formation Pattern Reference “Ice Formation Pattern” on page 137
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on the
entire evaporator
Ice formation is extremely
thin on outlet of
evaporator
-or-
No ice formation on entire
evaporator
Ice formation normal
-or-
Ice formation is extremely
thin on inlet of evaporator
-or-
No ice formation on entire
evaporator
Ice formation normal
-or-
No ice formation on entire
evaporator
