Manitowoc Indigo ID0502A User Manual

Part Number STH025 11/16 237
I0600 SERIES
I0600A
Self-Contained Air-Cooled Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 7.6-9.0 9.5-11.2 10.2-12.0
1-2.5
80/27 8.8-10.4 9.9-11.7 10.5-12.3
90/32 9.7-11.4 11.0-12.9 11.4-13.4
100/38 11.1-13.1 12.3-14.4 12.8-15.0
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 650 540 505
80/27 575 520 495
90/32 530 475 460
100/38 470 430 415
1 Based on average ice slab weight of 4.12 - 4.75 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 220-255 45-27 140-160 60-80
70/21 220-270 45-28 145-170 70-90
80/27 230-300 50-30 165-185 75-95
90/32 265-345 54-32 180-215 80-105
100/38 300-395 60-35 210-245 85-120
110/43 340-430 65-39 240-280 100-140
1 Suction pressure drops gradually throughout the freeze cycle
