Manitowoc Indigo ID0502A User Manual

262 Part Number STH025 11/16
I1406N
Remote Air-Cooled Condenser Model
Characteristics vary depending on operating conditions.
CYCLE TIMES
Freeze Time + Harvest Time = Total Cycle Time
Air Temp.
Entering
Condenser
°F/°C
Freeze Time
Harvest
Time
1
Water Temperature °F/°C
50/10 70/21 90/32
70/21 12.3-14.1 12.7-14.7 13.7-15.8
0.75-2.0
80/27 12.3-14.2 12.8-14.9 14.0-16.1
90/32 12.4-14.3 13.9-15.9 14.7-17.0
100/38 12.8-14.9 14.1-16.3 15.3-17.7
110/43 13.3-15.4 14.5-16.7 16.0-18.5
1 Times in minutes
24 HOUR ICE PRODUCTION
Air Temp. Entering
Condenser °F/°C
Water Temperature °F/°C
1
50/10 70/21 90/32
70/21 1490 1360 1240
80/27 1435 1325 1235
90/32 1355 1295 1230
100/38 1290 1185 1100
110/43 1160 1275 1000
1 Based on average ice slab weight of 10.25- 11.50 lb.
OPERATING PRESSURES
Air Temp
Entering
Condenser
°F/°C
Freeze Cycle Harvest Cycle
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
Discharge
Pressure
PSIG
Suction
Pressure
PSIG
1
50/10 205-220 50-32 100-150 75-100
70/21 225-260 60-32 110-160 75-100
80/27 240-170 60-32 110-160 75-100
90/32 250-270 60-32 120-160 80-100
100/38 300-375 85-35 130-170 80-100
110/43 310-375 90-36 130-170 80-100
1 Suction pressure drops gradually throughout the freeze cycle
