SETUP AND INSTALLATION MLC90A-1/MLC100-1 OPERATOR MANUAL
4-84
Published 12-10-19, Control # 258-05
Secure Operator Cab
1. If not already done, disable and store the remote control
in the left-front enclosure as shown in Figure 4-4 on
page 4-6.
2. In the cab:
• Stop the engine.
• Park all crane functions.
• Turn off all accessories.
• Remove all keys from the control console.
• Close and latch all windows.
3. Close and lock the cab door.
4. Rotate the cab mirror (1, Figure 4-6
) to the stored
position.
Lower Handrails
To lower the handrails, reverse the steps for "Raise
Handrails" on page 4-13.
Store Crane Platforms
To store the crane platforms, reverse the steps for Deploy
Crane Platforms on page 4-9.
Store Crawler Steps
To store the crawler steps, reverse the steps for Deploy
Crawler Steps on page 4-9.
Prepare Trailer for Travel
1. Store the trailer deck.
2. Attach the goose neck and the truck.
3. Verify that the crane is securely attached to the trailer.
Read Shipping Crane Components on page 4-61
.
BOOM #290 DISASSEMBLY
The following instructions assume that the boom and jib
have already been lowered to the ground and the load lines
have been stored.
The following instructions also assume that the boom butt
has been disconnected from the boom and the is being used
to disassemble the boom sections.
1. If not already done, remove and store the block-up limit
chains and weights.
2. Disconnect and store the electric cables between the
boom and jib or between the boom and upper boom
point.
3. If equipped remove the following:
• #117 jib (see "Jib #117 Disassembly" on page 4-85
)
• Upper boom point (reverse the installation steps on
page 4-51
).
• If equipped, disconnect and store the wind speed
and position light components so they are not
damaged during shipping.
• If equipped, disconnect and store the boom top
camera so it is not damaged during shipping.
4. Disconnect and remove the boom pendants. Reverse
the steps for "Install Boom Pendants" on page 4-50
.
5. Disassemble the boom sections and place them on
trailers for shipping:
• Reverse the steps for Install Boom Pendants on
page 4-50 and for Install Intermediate Suspension
Pendants on page 4-51.
• Reverse the steps for "Connect Boom Top to
Inserts" on page 4-49.
• Reverse the steps for "Assemble Boom Inserts" on
page 4-49.
• See Figure 4-12 on page 4-20
for handling the
boom sections.
DANGER
Collapsing Boom Hazard!
To prevent death or serious injury, do not stand on, inside,
or under the boom sections during boom disassembly.
Always stand outside the boom sections when removing
connecting pins.
