Page #271 background image
Part Number 80-1230-9 10/10 271
RFC2085 CONDENSING UNIT 230/60/1 – 230/50/1
(Diagram Shown in Freeze Cycle)
Refer to Nameplate for Voltage Rating
GROUND
(94)
(74)
(96)
(95)
L1
(44)
(43)
(48)
(50)
SV3014
(46)
(49)
(45)
(47)
COMPRESSOR
CRANKCASE
HEATER
HIGH
PRESSURE
CUTOUT
LOW
PRESSURE
CUTOUT
CONTACTOR
COIL
RUN
CAPACITOR
L2
RUN
CAPACITOR
RELAY
2
51
S
C
R
OVERLOAD
FAN MOTOR
CONTACTOR
CONTACTS
CONTACTOR
CONTACTS
START
CAPACITOR

Table of Contents

Other manuals for Manitowoc QF0400

Preview: Installation, Use & Care Manual
Installation, Use & Care Manual44 pages

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Manitowoc QF0400 and is the answer not in the manual?

Manitowoc QF0400 Specifications

General IconGeneral
ModelQF0400
Width30 inches
Voltage115V
CondenserAir-cooled
Water Connection3/8" FPT
RefrigerantR-404A
TypeUndercounter
Ice Production400 lbs per day
Ice TypeCube
Weight180 lbs
Power Supply115V, 60Hz
Water Usage4.5 gallons per 100 lbs of ice
