C
Rear fog lamp
D
License plate lamp
E
Backup lamps
X
Switch off the lighting system.
X
Undo screws : and remove lamp lens ;.
X
Applying light pressure to the bulb, turn it
counter-clockwise and remove it from the
bulb holder.
X
Press the new bulb into the bulb holder and
screw it in clockwise.
X
Position lamp lens ; and tighten screws :.
Additional lamps
Additional turn signal lamp on the roof
Type of lamp: P 21 W
X
Switch off the lighting system.
X
Undo screws : and remove lamp lens ;.
X
Applying light pressure to the bulb, turn it
counter-clockwise and remove it from the
bulb holder.
X
Press the new bulb into the bulb holder and
screw it in clockwise.
X
Position lamp lens ; and tighten screws :
again.
Perimeter lamp (Cab Chassis)
Type of lamp: W 5 W
X
Switch off the lighting system.
X
Undo screws : and remove the lamp unit.
X
Turn bulb holder ; and remove it.
X
Remove the bulb from bulb holder ;.
X
Press the new bulb into bulb holder ;.
X
Screw bulb holder ; into the lamp unit.
X
Carefully position the lamp housing and
tighten screws :.
Courtesy lights, rear compartment
Bulb type: W5W
X
Press in the latching spring of courtesy
light : with a suitable implement, e.g. a
screwdriver.
X
Pry off courtesy light :.
X
Disconnect cable connector =.
X
Unscrew bulb holder ;.
Changing bulbs
91
Lights and windshield wipers
