Towing
Towing
107
Guidelines for Breakdown Services (Subject to technical modifications)
i
Notes on stopped engine, transmission and/or axle damage
Stopped engine
Comply with section entitled "Towing with a tow bar", see page 111.
왘 Remove propeller shaft to drive axles complete.
왘 If it is not possible to remove the propeller shaft, remove the appropriate drive shafts, see page 109.
왘 All-wheel drive vehicles: Switch transfer case to road position.
왘 Ensure that the compressed air supply is provided by the towing vehicle.
Transmission/transfer case damage
왘 Remove propeller shaft to drive axles complete.
Front axle damage
왘 Raise vehicle at front axle.
왘 Deactivate acceleration skid control (ASR), see page 103.
왘 All-wheel drive vehicles: Remove the propeller shaft between the rear axle and transfer case.
왘 On vehicles with air suspension: Set the required chassis height with the operating unit, see page 86.
Damage to the rear axle differential
왘 On vehicles with more than one driven axle or insufficient air pressure in the compressed air system: Engage
differential lock with bolt,
see page 109.
왘 Remove both drive shafts on the damaged axle, see page 109.
왘 On vehicles with two driven rear axles: Remove drive shafts on both driven rear axles.
왘 All-wheel drive vehicles: Also remove the propeller shaft from the front axle to the transfer case.
Risk of injury G
A propeller shaft may fall down and injure you when being removed. Secure the propeller shaft prior to
removal to prevent it from falling, e.g. with the aid of a second person or by tying up the propeller shaft.
Do not turn the vehicle key in the steering lock to the drive position when the front axle is raised. Otherwise
the automatic ASR function may cause uncontrolled braking of the rear wheels may while the vehicle is being
towed. This can cause the vehicle to lose lateral stability and break away.
!
Observe the towing instructions as for a stopped engine, see above.
