Towing
Towing
109
Guidelines for Breakdown Services (Subject to technical modifications)
i
Removing the rear axle drive shafts
Engaging differential lock with bolt (HL4):
왘 Remove cable connector 1 from shift cylinder
housing
2.
왘 Unscrew switch using socket wrench (size
24
mm).
왘 Carefully screw bolt 3 all the way into shift cyl-
inder housing 2.
Bolt M 18 x 1.5 x 60 mm
Special tools, see page 121.
왘 If it is not possible to screw the bolt 3 all the
way in: Pull out drive shaft about 150
mm and
twist until the bolt
3 can be screwed fully home.
(example)
(example)
