CHARGING & STARTING SYSTEM
90-883728 JULY 2001 Page 2B-11
Flywheel/Alternator
TORQUE
.
NO.
QTY. DESCRIPTION lb. in. lb. ft. Nm
1 1 ALTERNATOR
2 1 SCREW (M10 x 100) 40 54
3 1 SCREW (M10 x120) 40 54
4 3 WASHER
5 3 MOUNT
6 1 BRACKET
7 3 WASHER
8 1 BRACKET
9 2 NUT 40 54
10 1 SCREW (M10 x 55) 40 54
11 1 CABLE
12 1 PIN
13 1 BRACKET
14 3 SCREW (5/16-18 x 1 IN.) 15.5 21
15 1 SPRING
16 1 BELT TENSIONER ARM ASSY
17 1 STUD (M10 x 85)
18 1 NUT 15 20
19 1 BUSHING
20 2 WASHER
21 1 PULLEY
22 1 SCREW (M10 x 35) 25 34
23 1 BELT
24 1 FLYWHEEL
25 1 NUT (M16X1.5) 125 170
26 1 WASHER
27 1 PLUG
28 1 NUT 110 9 12
29 1 WASHER
30 1 J CLAMP
To Next Page
