LEFT HAND NON-RATCHETING
90-883728 JULY 2001 Page 6B-11
Gear Housing (Prop Shaft)(Counter Rotation)
TORQUE
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm.
1 1 GEAR HOUSING (BLACK)(BASIC)
67 1 ROLLER BEARING
68 1 THRUST WASHER
69 1 BEARING ADAPTOR ASSEMBLY
70 1 ROLLER BEARING
71 2 THRUST WASHER
72 2 THRUST BEARING
73 2 THRUST RACE
74 2 KEEPER
75 1 O RING
76 1 BEARING CARRIER ASSEMBLY
77 1 ROLLER BEARING
78 1 OIL SEAL (INSIDE)
79 1 OIL SEAL (OUTSIDE)
80 1 TAB WASHER
81 1 KEY
82 1 COVER 210 285
83 1 TRIM TAB
84 1 SCREW (1-3/4 IN.) 25 34
85 1 SCREW (3/8-16 x 1) 30 41
86 2 WASHER
87 2 NUT 50 68
General Service Recommendations
There may be more than one way to “disassemble” or “reassemble” a particular part(s),
therefore, it is recommended that the entire procedure be read prior to repair.
IMPORTANT: Read the following before attempting any repairs.
In many cases, disassembly of a sub-assembly may not be necessary until cleaning and
inspection reveals that disassembly is required for replacement of one or more compo-
nents.
Service procedure order in this section is a normal disassembly-reassembly sequence.
It is suggested that the sequence be followed without deviation to assure proper repairs.
When performing partial repairs, follow the instructions to the point where the desired
component can be replaced, then proceed to “reassembly and installation” of that compo-
nent in the reassembly part of this section. Use the “Index” (on back of section divider)
to find correct page number.
Threaded parts are right hand (RH), unless otherwise indicated.
When holding, pressing or driving is required, use soft metal vise jaw protectors or wood
for protection of parts. Use a suitable mandrel (one that will contact only the bearing race)
when pressing or driving bearings.
Whenever compressed air is used to dry a part, verify that no water is present in air line.
