FUEL INJECTION

90-883728 JULY 2001 Page 3B-51

3. Apply 2-4-C with Teflon to lips of seal in separator cover.

58787

58783

a-Screw [Torque to 10 lb. in. (1.0 Nm)]

b-Float

c-Gasket

d-Sealing Bead

e-Seal (Seal shoulder faces OUT)

4. Connect electrical harness to fuel pump. Inspect fuel pump filter screen for debris. Re-

move screen and clean as required.

5. Seat fuel pump and harness into separator cover being careful not to pinch harness.

58786

a-Harness

b-Filter

c-Seal

d-Fuel Pump

Questions and Answers:

Need help?

Do you have a question about the Mercury 150 EFI and is the answer not in the manual?

Mercury 150 EFI Specifications

General

Engine Type	4-stroke
Displacement	3.0L
Horsepower	150 HP
Fuel Induction System	Electronic Fuel Injection (EFI)
Alternator	60 amp / 756 watt
Gear Ratio	1.92:1
Cylinders	4
Starting	Electric
Warranty	3 years
Shaft Length	20", 25"
Weight	455 lbs
Full Throttle RPM Range	5000-5800 RPM
