POWERHEAD
90-883728 JULY 2001 Page 4A-27
Ignition Coil Plate and Harness Removal
Disconnect the following:
58893
b
c
d
i
h
g
e
f
a
f
f
f
g
j
a-Speedometer Sensor
b-Port Temperature Sensor
c-Water Pressure Sensor
d-Starboard Temperature Sensor
e-Ignition Coil Harness Connector
f-Bolts (4)
g-Spark Plug Leads (Use proper tool to remove spark plug boot to avoid damage
to boot)
h-Speedometer Hose
i-Water Pressure Hose
j-Temperature Gauge Bullet Connector
