Mercury 150 EFI User Manual

CLAMP/SWIVEL BRACKETS & DRIVESHAFT HOUSING
90-883728 JULY 2001 Page 5A-7
Drive Shaft Housing and Exhaust Tube
REF
TORQUE
REF
.
NO.
QTY. DESCRIPTION lb-in lb-ft Nm
1
1 DRIVE SHAFT HOUSING (LONG)
1
1 DRIVE SHAFT HOUSING (X-LONG)
2 2 STUD
3 2 SCREW (1/2-20 x 6 IN.)
4 1 GROUND WIRE
5 2 LOWER MOUNT
6 2 WASHER
7 1 GROUND WIRE
8 2 NUT 50 68
9 1 SCREW (1/4-20 x 3/8 IN.)
10 2 WASHER
11 2 NUT 50 68
12 2 CLAMP
13 4 SCREW (5/16-18 x 1-1/4 IN.) 22 30
14 2 COVER
15 4 SCREW (12-24 x 5/8 IN.) 17 2
16 4 NUT 25 34
17 1 WASHER
18 1 NUT 57 77
19 4 WASHER
20 4 NUT 23 31
21 1 IDLE EXHAUST BOOT
22 1 PLUG
23 1 GASKET
24 1 SEAL (LOWER)
25 1 EXHAUST TUBE
26 1 SEAL (UPPER)
27 1 EXHAUST EXTENSION
28
1 WATER TUBE (LONG)
28
1 WATER TUBE (X-LONG)
29 1 PLATE ASSEMBLY
30 1 SEAL
31 1 BRACKET
32 12 SCREW (10-16 x 1/2 IN.) 80 9
33 2 DOWEL PIN
34 1 SEAL
35 6 SCREW (1/4-20 x 3/4 IN.) 60 7
36 1 GASKET
