LEFT HAND NON-RATCHETING
Page 6B-58 90-883728 JULY 2001
Speedometer Tube Installation
1. Route speedometer tube from gearcase around lower yoke and push into junction.
Junction should be secured to yoke with sta-strap.
2. Route speedometer tube from swivel tube around lower yoke and push into junction.
After insertion of speedometer tubes into junction, pull on each tube to verify that they
are locked into junction. If tube pulls out, reinsert into junction.
57735
57736
a
d
a
c
b
d
a-Speedometer Tube from Gearcase
b-Junction
c-Sta-strap
d-Speedometer Tube from Swivel Tube

Mercury 150 EFI Specifications

General

Engine Type	4-stroke
Displacement	3.0L
Horsepower	150 HP
Fuel Induction System	Electronic Fuel Injection (EFI)
Alternator	60 amp / 756 watt
Gear Ratio	1.92:1
Cylinders	4
Starting	Electric
Warranty	3 years
Shaft Length	20", 25"
Weight	455 lbs
Full Throttle RPM Range	5000-5800 RPM
