WIRING DIAGRAMS
90-883728 JULY 2001 Page 2D-61
Tachometer Calibration
NOTE: When calibrating multi tachometers (multi engines) turn ignition on for all the
tachometers.
Simple Calibration – This calibration for setting lighting and a few other common screens
can be made while engine is running.
1. Press in the
MODE
and
TROLL
+
buttons for calibration screen.
2. Press
MODE
to advance through the calibration selections.
Advanced Calibration – This calibration goes through the entire mode selections.
1. Turn ignition key to the off position.
2. Hold
TROLL
+
TROLL
–
and turn ignition on.
3. Press and hold
MODE
for 2 seconds to bring up the calibration screen.
4. Press
MODE
to advance through the calibration selections.
[DOWN]
CALIBRATION
BRIGHTNESS
[UP]
[SAVE]
Press – or + to adjust level. Press MODE to save setting
CALIBRATION
BRIGHTNESS
[ YES ]
[ NO ]
SET ALL INSTRUMENTS?
Do you want the same brightness level for all SmartCraft
gauges? Press + for yes. Press MODE for no.
[DOWN]
CALIBRATION
[UP]
[SAVE]
CONTRAST
Press – or + to adjust level. Press MODE to save setting
CONTRAST
CALIBRATION
[ YES ]
[ NO ]
SET ALL INSTRUMENTS?
Do you want the same contrast level for all SmartCraft
gauges? Press + for yes. Press MODE for no.
CALIBRATION
[DOWN]
CONTROL OPTIONS
[UP]
[SAVE]
REMOTE SCREEN ? YES – NO
Multi Engine – Do you want tachometer display screens to
advance together? Press + or – to select. Press MODE to
save.
CALIBRATION
[DOWN]
CONTROL OPTIONS
[UP]
[SAVE]
TRIM POP UP ? YES – NO
Do you want power trim angle display screen to pop up when-
ever you trim the outboard ? Press + or – to select. Press
MODE to save.
CALIBRATION
[DOWN]
ENGINE POSITION
[UP]
[SAVE]
SINGLE-PORT-CENTER-STARBOARD
Match tachometer to the correct engine. Press + to select
engine. Press MODE to save.
[DOWN]
[UP]
[SAVE]
CALIBRATION
DISPLAY UNITS
ENGLISH - METRIC
Select display readings in English or Metric. Press + or – to
select Press MODE to save.
To Next Page
