GENERAL INFORMATION
20
WHILE YOU ARE CRUISING
It is very difficult for a person standing or floating in the water to
take quick action to avoid a boat heading in their direction even at
slow speed.
Always slow down and exercise extreme caution any time you are
boating in an area where there might be people in the water.
Avoid shallow water or where any loose material such as sand,
shells, seaweed, grass, tree branches, etc. can be sucked in and
expelled from the pump as a high speed projectile.
WHILE BOAT IS STATIONARY
Stop the Mercury Jet Drive engine immediately whenever anyone
in the water is near your boat. The Mercury Jet Drive is always
drawing water through the water intake grate when the engine is
running. Stay away from the water intake located under the stern
(back) of the boat and never insert an object into the water intake
or water outlet nozzle when the engine is running.
!
WARNING
Avoid injury resulting from contacting the rotating impeller or
having hair, clothing, or loose objects drawn into the water intake
and wrapping around the impeller shaft. Stay away from the
water intake and never insert an object into the water intake or
water outlet nozzle when the engine is running.
Exhaust Emissions
BE ALERT TO CARBON MONOXIDE POISONING
Carbon monoxide (CO) is a deadly gas that is present in the
exhaust fumes of all internal combustion engines, including the
engines that propel boats, and the generators that power boat
accessories. By itself, CO is odorless, colorless, and tasteless, but
if you can smell or taste engine exhaust, you are inhaling CO.
Early symptoms of carbon monoxide poisoning, which are similar
to the symptoms of seasickness and intoxication, include
headache, dizziness, drowsiness, and nausea.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Mercury 200 SportJet and is the answer not in the manual?

Mercury 200 SportJet Specifications

General IconGeneral
Model200
Horsepower200
Kilowatts149.1
Full throttle RPM range5150–5650
Idle speed RPM range900–1000
Number of cylinders6
Piston displacement2508 cc (153 in³)
Cylinder bore88.4 mm (3.500 in.)
Stroke67.3 mm (2.650 in.)
Spark plugNGK IZFR6J‑11
Spark plug gap1.1 mm (.043 in.)
Recommended gasolineRefer to Fuel and Oil
Recommended oilRefer to Fuel and Oil
Emission control systemElectronic engine control (EC)
Battery rating (minimum)1000 marine cranking amps (MCA) or 800 cold cranking amps (CCA)
Charging system output60 A
