Mercury 200 SportJet User Manual

MAINTENANCE
60
Compressor Air Intake Filter
The filter should be changed every 100 hours of operation, or once
a season.
IMPORTANT: Never run the engine without the air filter.
REMOVAL
1. Remove flywheel cover from engine.
2. Snap out the retainer and remove filter.
a - Retainer
b - Filter
INSTALLATION
1. Install filter into cover.
2. Secure filter into cover with retainer.
Belt Tensioner Idler Pulley Lubrication
Lubricate through the fitting with 2‑4‑C with Teflon.
29399
b
a
29397

Mercury 200 SportJet Specifications

General

Model	200
Horsepower	200
Kilowatts	149.1
Full throttle RPM range	5150–5650
Idle speed RPM range	900–1000
Number of cylinders	6
Piston displacement	2508 cc (153 in³)
Cylinder bore	88.4 mm (3.500 in.)
Stroke	67.3 mm (2.650 in.)
Spark plug	NGK IZFR6J‑11
Spark plug gap	1.1 mm (.043 in.)
Recommended gasoline	Refer to Fuel and Oil
Recommended oil	Refer to Fuel and Oil
Emission control system	Electronic engine control (EC)
Battery rating (minimum)	1000 marine cranking amps (MCA) or 800 cold cranking amps (CCA)
Charging system output	60 A
