Mercury 200 SportJet User Manual

MAINTENANCE
61
Tube Ref
No.
Description Where Used Part No.
95
2-4-C with
Teflon
Tensioner pulley grease fitting 92-802859A 1
Flushing the Cooling System
Flushing the cooling system is essential after each use in saltwater,
after the boat has run aground, or when the overheat warning horn
sounds. When using the flushing attachment, ensure that the water
is turned all the way on and flowing through the engine before
starting.
IMPORTANT: When using the flushing attachment do not run the
engine above idle.
!
CAUTION
Never start or run the jet drive without water circulating through
the cooling system to prevent damage to the unit.
a - Flushing attachment (hull
mount)
b - Flushing attachment
(engine compartment
mount)
1. Locate the flush adapter in the boat. Some boats may have
the adapter mounted in the hull or mounted in the engine
compartment.
2. With engine "OFF," remove the cap from the flush adapter and
attach a water hose.
IMPORTANT: Do not run the engine above idle when flushing.
3. Turn the water on all the way. Start the engine and flush the
engine block for at least 10 minutes.
a
b
5469

Mercury 200 SportJet Specifications

General

Model	200
Horsepower	200
Kilowatts	149.1
Full throttle RPM range	5150–5650
Idle speed RPM range	900–1000
Number of cylinders	6
Piston displacement	2508 cc (153 in³)
Cylinder bore	88.4 mm (3.500 in.)
Stroke	67.3 mm (2.650 in.)
Spark plug	NGK IZFR6J‑11
Spark plug gap	1.1 mm (.043 in.)
Recommended gasoline	Refer to Fuel and Oil
Recommended oil	Refer to Fuel and Oil
Emission control system	Electronic engine control (EC)
Battery rating (minimum)	1000 marine cranking amps (MCA) or 800 cold cranking amps (CCA)
Charging system output	60 A
