Mercury 200 SportJet User Manual

OPERATION
41
The engine break‑in procedure for your OptiMax engine is
important to ensure proper performance and maximum life from
the engine. The following break‑in procedure allows the internal
engine parts to wear‑in evenly. Incorrect engine break‑in can
shorten the engine life.
The engine automatically receives extra oil during the first hours
of operation. For most boaters, this extra oil mode will be complete
in about ten hours.
First hour
• Allow engine to warm‑up for 30–60 seconds.
• Avoid continuous operation at idle speed for more than 10
minutes.
• Run the engine the majority of time between 3000–4500 RPM,
approximately three quarter throttle.
• Vary engine speed; change engine speed approximately
every two minutes.
• Short bursts of full throttle for periods up to 10 seconds are
acceptable.
Next three hours
• Change engine speed every 10 minutes.
Starting the Engine
Before starting, read the Pre-Starting Check List, Special
Operating Instructions, and Engine Break-In Procedure.
!
WARNING
Explosive fumes contained in the engine compartment can cause
serious injury or death from fire or explosion. Before starting the
engine, operate the bilge blower or vent the engine compartment
for at least five minutes.

Mercury 200 SportJet Specifications

General

Model	200
Horsepower	200
Kilowatts	149.1
Full throttle RPM range	5150–5650
Idle speed RPM range	900–1000
Number of cylinders	6
Piston displacement	2508 cc (153 in³)
Cylinder bore	88.4 mm (3.500 in.)
Stroke	67.3 mm (2.650 in.)
Spark plug	NGK IZFR6J‑11
Spark plug gap	1.1 mm (.043 in.)
Recommended gasoline	Refer to Fuel and Oil
Recommended oil	Refer to Fuel and Oil
Emission control system	Electronic engine control (EC)
Battery rating (minimum)	1000 marine cranking amps (MCA) or 800 cold cranking amps (CCA)
Charging system output	60 A
