MAINTENANCE
46
EMISSION CERTIFICATION LABEL
An emission certification label, showing emission levels and
engine specifications directly related to emissions, is placed on the
engine at the time of manufacture.
a - Idle speed
b - Engine horsepower
c - Piston displacement
d - Engine power ‑ kilowatts
e - Date of manufacture
f - Family number
g - Regulated emission limit for the engine family
h - Regulated emission limit for the engine family
i - Recommended spark plug and gap
j - Percent of fuel line permeation
OWNER RESPONSIBILITY
The owner/operator is required to have routine engine
maintenance performed to maintain emission levels within
prescribed certification standards.
The owner/operator is not to modify the engine in any manner that
would alter the horsepower or allow emission levels to exceed their
predetermined factory specifications.
Inspection and Maintenance Schedule
PRIOR TO EVERY USE
• Check that lanyard stop switch stops the engine.
• Visually inspect the fuel system for deterioration or leaks.
SPARK PLUG:
GAP:
EMISSION CONTROL
INFORMATION
THIS ENGINE CONFORMS TO
EMISSION REGULATIONS FOR SPARK IGNITION MARINE ENGINES
CALIFORNIA AND U.S. EPA
REFER TO OWNERS MANUAL FOR REQUIRED MAINTENANCE,
SPECIFICATIONS, AND ADJUSTMENTS
IDLE SPEED (in gear):
FAMILY:
HC+NOx:FEL:
LOW PERM/HIGH PERM:
g/kWh
hp
L
e
d
c
b
a
f
g
h
i
HC+NOx:FEL:
g/kWh
hp
L
CO FEL:
g/kWh
kw
g/kWh
j
43210

Mercury 200 SportJet Specifications

General

Model	200
Horsepower	200
Kilowatts	149.1
Full throttle RPM range	5150–5650
Idle speed RPM range	900–1000
Number of cylinders	6
Piston displacement	2508 cc (153 in³)
Cylinder bore	88.4 mm (3.500 in.)
Stroke	67.3 mm (2.650 in.)
Spark plug	NGK IZFR6J‑11
Spark plug gap	1.1 mm (.043 in.)
Recommended gasoline	Refer to Fuel and Oil
Recommended oil	Refer to Fuel and Oil
Emission control system	Electronic engine control (EC)
Battery rating (minimum)	1000 marine cranking amps (MCA) or 800 cold cranking amps (CCA)
Charging system output	60 A
