Midea MGC-F16W/SN1 User Manual

MCAC-TSM-2008-02 Outdoor units
Outdoor units 21
7. Capacity Tables
Cooling
MGC-F05W/N1
Ta
Tw 5.0 6.0 7.0 8.0 9.0 10.0
Pf 5.1 5.2 5.4 5.5 5.6 5.8
Pa 1.5 1.5 1.5 1.5 1.6 1.6
Pat 1.8 1.8 1.8 1.8 1.9 1.9
Qev 0.88 0.89 0.93 0.95 0.96 1.00
25.0
ΔPev 21.6 23.0 24.6 26.3 27.8 29.5
Pf 4.9 5.0 5.1 5.3 5.4 5.5
Pa 1.8 1.8 1.8 1.8 1.9 1.9
Pat 2.1 2.1 2.1 2.1 2.2 2.2
Qev 0.84 0.86 0.88 0.91 0.93 0.95
30.0
ΔPev 18.4 19.7 22.1 23.6 25.1 26.6
Pf 4.8 4.9 5.0 5.1 5.2 5.3
Pa 1.8 1.8 1.8 1.9 1.9 1.9
Pat 2.1 2.1 2.1 2.2 2.2 2.2
Qev 0.83 0.84 0.86 0.88 0.89 0.91
35.0
ΔPev 18.5 19.8 21.0 22.5 24.0 25.5
Pf 4.6 4.7 4.9 5.0 5.1 5.2
Pa 1.9 1.9 1.9 2.0 2.0 2.0
Pat 2.2 2.2 2.2 2.3 2.3 2.3
Qev 0.79 0.81 0.84 0.86 0.88 0.89
40.0
ΔPev 17.1 18.3 19.6 20.9 22.3 23.7
Pf 4.3 4.5 4.6 4.7 4.9 5.0
Pa 2.1 2.1 2.1 2.2 2.2 2.2
Pat 2.4 2.4 2.4 2.5 2.5 2.5
Qev 0.74 0.77 0.79 0.81 0.84 0.86
43.0
ΔPev 14.8 15.9 17.1 18.3 19.5 20.8
Note:
Ta: outside air temperature (°C)
Tw : evaporator water outlet temperature (°C)
Pf: cooling capacity (kW)
Pa: compressor power input (kW)
Pat: total power input (kW)
Qev: evaporator water flow (m
3
/h)
ΔPev: evaporator pressure drop (kPa)
