MCAC-TSM-2008-02 Electrical Connection
Installation 73
It consists of a remote control module.
To install the kit, proceed as follows:
- disconnect the power supply and then access the inside f the electrical panel;
- connect the remote control module with 3 wires to terminals 15, 16 and 17 on the installer terminal board:
connect terminal 15 to terminal Black/gnd on the module;
connect terminal 16 to terminal Blue/signal on the module;
connect terminal 17 to terminal Red/+12v on the module;
Important
To avoid interference due to magnetic fields, the use of shielded cable is recommended. The cable should
not be more than 100m long.
The Specification of Power:
Type MGC-F05W/N1 MGC-F07W/N1 MGC-F09W/N1 MGC-F10W/N1
Power 220~240-1-50 220~240-1-50 220~240-1-50 220~240-1-50
Circuit breaker/fuse (A) 25/20 30/25 40/25 40/35
Power wiring (mm
2
) 3×2.5 3×2.5 3×4.0 3×4.0
Ground wiring (mm
2
) 2.5 2.5 4.0 4.0
Outdoor /Indoor connecting wiring (mm
2
) 1.0 1.0 1.0 1.0
Type MGC-F10W/SN1 MGC-F12W/SN1 MGC-F14W/SN1 MGC-F16W/SN1
Power 380~415-3-50 380~415-3-50 380~415-3-50 380~415-3-50
Circuit breaker/fuse (A) 25/15 25/15 25/15 30/20
Power wiring (mm
2
) 5×2.5 5×2.5 5×2.5 5×4.0
Ground wiring (mm
2
) 2.5 2.5 2.5 4.0
Outdoor /Indoor connecting wiring (mm
2
) 1.0 1.0 1.0 1.0
Important
The power cord type designation is H07RN-F.
Connecting cable between indoor unit and outdoor unit shall be approved poly-chloroprene sheathed flexible
cord, type designation H07RN-F or heavier cord.
The means for disconnection from a power supply shall be incorporated in the fixed wiring and have an air
gap contact separation of at least 3mm in each active(phase) conductors.
