Miele H 2890 B User Manual

Cleaning and care
55
Door removal
The door weighs approx. 11kg.
The oven door is connected to the door
hinges by retainers.
Before removing the door from the
retainers, the locking clamps on both
door hinges have to be released.
 Open the door fully.
 Release the locking clamps by
turning them as far as they will go.
The oven could become damaged if
you incorrectly remove the door.
Never pull the door horizontally off its
retainers, as they will spring back
against the oven.
Never pull the door off the retainers
by the handle, as the handle could
break off.
 Raise the door up till it rests partially
open.
 Hold the door on either side and pull
it diagonally upwards off the
retainers. Make sure that the door
goes back on straight.

Miele H 2890 B Specifications

General

Fast heat	Yes
Oven size	Large
Oven type	Electric
Self-cleaning	-
Number of ovens	1
Total oven power	- W
Oven thermostat range	50 - 270 °C
Number of shelf positions	3
Total oven(s) interior capacity	90 L
Current	16 A
Connected load	3700 W
AC input voltage	220–240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy consumption (conventional)	1.45 kWh
Energy consumption (forced convection)	0.89 kWh
Door hinge	down
Cord length	1.7 m
Control type	Rotary
Product color	Black, Stainless steel
Control position	Front
Appliance placement	Built-in
Clock type	Electronic
Timer modes	Cooking time, End cooking time, Timer
Lamp type	Halogen
Lamps quantity	2 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	895 mm
Height	478 mm
Weight	64000 g
Installation compartment depth	550 mm
Installation compartment height	517 mm
Installation compartment width (min)	860 mm
