Miele H 2890 B User Manual

Installation
*
I
N
S
T
A
L
L
A
T
I
O
N
*
71
Installing the oven
For safety reasons, the oven may
only be used when it has been fully
installed.
The oven requires a sufficient supply
of cool air for efficient operation. The
required supply of cool air must not
be excessively heated by other heat
sources (e.g. solid fuel stoves).
The following must be observed
when installing the appliance:
Make sure that the shelf that the
oven sits on does not touch the wall.
Do not fit heat insulation strips to the
side walls of the housing unit.
 Connect the oven to the electrical
supply.
Do not carry the oven by the door
handle. The door can be damaged.
Use the handle cut-outs on the side
of the housing to lift the appliance.
It is a good idea to remove the door
(see “Cleaning and care” – “Removing
the door”) and to remove the
accessories before installing the
appliance. This makes the oven lighter
when you push it into the housing unit
and you do not run the risk of lifting it
by the door handle by mistake.
 Remove the carrying handles.
 Push the oven into the housing unit
and align it.
 Open the door, if you have not
removed it.
 Use the screws supplied to secure
the oven to the side walls of the
housing unit.
 Refit the door if necessary (see
“Cleaning and care” – “Fitting the
door”).

Miele H 2890 B Specifications

General

Fast heat	Yes
Oven size	Large
Oven type	Electric
Self-cleaning	-
Number of ovens	1
Total oven power	- W
Oven thermostat range	50 - 270 °C
Number of shelf positions	3
Total oven(s) interior capacity	90 L
Current	16 A
Connected load	3700 W
AC input voltage	220–240 V
AC input frequency	50 Hz
Energy efficiency scale	A+++ to D
Energy consumption (conventional)	1.45 kWh
Energy consumption (forced convection)	0.89 kWh
Door hinge	down
Cord length	1.7 m
Control type	Rotary
Product color	Black, Stainless steel
Control position	Front
Appliance placement	Built-in
Clock type	Electronic
Timer modes	Cooking time, End cooking time, Timer
Lamp type	Halogen
Lamps quantity	2 lamp(s)

Weight and Dimensions

Depth	568 mm
Width	895 mm
Height	478 mm
Weight	64000 g
Installation compartment depth	550 mm
Installation compartment height	517 mm
Installation compartment width (min)	860 mm
