Technical Information
103
G 1xxx/G 2xxx
2. Remove the top basket.
3. Unscrew the screw connection and remove the spray arm.
4.5 Removing the Middle Spray Arm
1. Remove the top basket.
2. Unscrew the screw connection and remove the spray arm.
4.6 Removing the Bottom Spray Arm
1. Remove the bottom basket.
2. Remove the spray arm.
4.7 Removing the Feed Pipe to the Top Spray Arm with Turbidity
Sensor
1. Remove the right side panel (see Section 010-4.1).
2. Disconnect the turbidity sensor plug connections.
3. Remove the top spray arm; see Section 050-4.4.
4. Unscrew the locknut.
5. Remove the drip pan. See Section 010-4.2.
6. Disconnect the hose clip connection to the circulation pump.
4.8 Removing the Feed Pipe to the Middle Spray Arm
1. Remove the right side panel (see Section 010-4.1).
2. Remove the top basket.
3. Dismantle the feed pipe on the rear panel inside the cabinet.
Note:
To release the feed pipe in the rear panel feed-through area, hold the
stub at the rear and pull it while at the same time pushing in the seal from
the inside with a suitable screwdriver to reduce its cross-sectional area.
4. Remove the drip pan. See Section 010-4.2.
5. Remove the right-side toekick.
6. Disconnect the hose clip connection to the circulation pump.
4.9 Replacing the Spray Arm Sensor
1. Remove the right side panel (see Section 010-4.1).
2. Remove the spray arm sensor.
3. Disconnect its plug connections.
