Technical Information
21
G 1xxx/G 2xxx
2.3 Door Springs Supplied as Spare Parts
Model Width Spring Color
Max. Front Panel
Weight [lbs (kg)]
G 118x VI 24" Green 33.0 (15)
G 1202 KST
1
18” Uncolored 27.5 (12.5)
G 1202 EDST
2
18" Uncolored 25.3 (11.5)
G 1262 VI 18” Uncolored 30.8 (14)
G 147x 24" Green 31 (14.1)
G 2020 24"
-- --
G 212x/ 214x/215x KST
1
24” -- --
G 212x/ 214x/215x EDST
2
24” -- --
G 2170, 218x VI 24”
-- --
G 2420, G 243x KST
1
24” -- --
G 2420, G 243x EDST
2
24”
-- --
G 247x 24” -- --
G 2630 24" -- --
G 2670 24"
-- --
G 2732 I, G 283x I KST
1
24" -- --
G 2732 I, G 283x I EDST
2
24"
-- --
G 287x VI 24” -- --
Table C-9: Door Springs Supplied as Spare Parts
1
Plastic fascia panel
2
Stainless-steel fascia panel
3 Electrical and Plumbing Connections
3.1 Electrical Information
The appliance is equipped with a 4-foot power cord and molded NEMA 515
plug for connection to a NEMA 5-15R receptacle (120VAC, 15-amp, 3-prong,
grounded outlet).
It is recommended that the power outlet for the appliance be installed on the
wall (within the cabinets), adjacent to under-counter space where the
appliance is installed.
Ensure that the cabinets contain no rough edges that could damage the
power cord or drain hose. If metal cabinets are used, ensure that a rubber
grommet is installed around the opening.
Always exercise caution when sliding the dishwasher in or out, to prevent
damaging the power cord and/or hoses.
