Technical Information
112
G 1xxx/G 2xxx
Note:
When installing, the following should be noted:
1. Install the sealing ring on the metal flange on the cabinet.
2. Apply liquid detergent as a lubricant to the outer surface of the seal.
3. Apply liquid detergent as a lubricant to the inside of the sump.
4. Before reusing the dishwasher, detergent residues must be flushed out
of the cabinet as otherwise these could cause a fault indication (see
Fault Code F52, Section 080-3.30).
5. Make sure that the arrows on the sump and cabinet base are aligned.
6. Align the sump with the connection to the drain. Install the cover and
filter combination.
7. Locate the clip lock in the middle between the two stoppers.
8. Tighten the hose clip on the sump.
Warning!
To prevent possible leakages later on, do not overtighten the clip on the
sump.
4.24 Removing the NTC Temperature Sensor
1. Open the door.
2. Remove the bottom basket.
3. Remove the bottom spray arm.
4. Remove the filter combination.
5. Remove as much residual water as possible from the sump and drain hose.
6. Lay the dishwasher onto its back.
7. Remove the drip pan. See Section 010-4.2.
8. Disconnect the NTC temperature sensor plug connections.
9. Remove the NTC temperature sensor.
10. Remove the sealing ring.
4.25 Removing the Float
1. Remove the drip pan. See Section 010-4.2.
2. Pull off the float.
Note:
When re-attaching the float, make sure that the side with the mat. no. faces
downwards.
4.26 Removing the Float Switch
1. Open the door.
2. Remove the bottom basket.
3. Remove the filter combination.
4. Remove as much residual water as possible from the sump and drain hose.
5. Lay the dishwasher onto its back.
