Technical Information

G 1xxx/G 2xxx

1.6 Advanta

Features Model

G 2020 G 2170

Width

24”

Height

Free-standing

N/A

Built-in

33.3” (adj. + 2.6”)

Sensor technology

ECO sensor III

Sensor softener

Spray arm sensing

None

SensorDry

Noise level

48dB

Heater rating

1300W

Circulation pump type

MPEH (without slide shutter)

Electrical connection

120VAC; 1.5kW; 15A

Water (flow) pressure

4.4 - 145 psi (0.3 - 10 bar)

Hot-water connection

Max. 140°F

Drain pump head height

Max. 3'4”

Drain hose length

Max. 13'1”

Salt container in door

Drying system

Circulation Turbothermic drying

Comfort door closing aid

Power cord length

Approx. 5'6”

Capacity

14 place settings

Table C-6: US Data Sheet, Advanta Models
