Technical Information

G 1xxx/G 2xxx

1.4 Excella, Excella II

Features Model

G 2630 G 2670 G 2732

Width

24”

Height

Free-standing

N/A

Built-in

33.3” (adj. + 2.6”)

Sensor technology

Autosensor

Sensor softener

Yes

Spray arm sensing Middle, bottom

SensorDry

No Yes

Noise level

42dB

Heater rating

1300W

Circulation pump type

MPEW

MPPW

Electrical connection

120VAC; 1.5kW; 15A

Water (flow) pressure

4.4 - 145 psi (0.3 - 10 bar)

Hot-water connection

Max. 140°F

Drain pump head height

Max. 3'4”

Drain hose length

Max. 13'1”

Salt container in door

Drying system

Recirculation Turbothermic drying

Comfort door closing aid

Power cord length

Approx. 5'6”

Capacity

14 place settings

Table C-4: US Data Sheet, Excella/Excella II Models

Circulation pump with slide shutter

Circulation pump with frequency converter and slide shutter
