G 1xxx/G 2xxx

1.5 LaPerla, LaPerla II

Features Model

G 2830 G 2832 G 2872

Width

24”

Height

Free-standing

N/A

Built-in

33.3” (adj. + 2.6”)

Sensor technology

Autosensor

Sensor softener

Yes

Spray arm sensing

Middle, bottom

SensorDry

No Yes Yes

Noise level

42dB 41dB 40dB

Heater rating

1300W

Circulation pump type

MPEW

MPPW

Electrical connection

120VAC; 1.5kW; 15A

Water (flow) pressure

4.4 - 145 psi (0.3 - 10 bar)

Hot-water connection

Max. 140°F

Drain pump head height

Max. 3'4”

Drain hose length

Max. 13'1”

Salt container in door

Yes

Drying system

Circulation Turbothermic drying

Comfort door closing aid

No Yes Yes

Power cord length

Approx. 5'6”

Capacity

14 place settings 16 place settings 16 place settings

Table C-5: US Data Sheet, LaPerla/LaPerla II Models
