Miele PDR 507 HP Marine User Manual

Technical data
81
Height 850mm
Width 596mm
Width (only for machines with a stain-
less steel lid)
605mm
Depth 777mm
Depth with door open 1191mm
Weight 72kg
Drum volume 130l
Load size 7kg (weight of dry laundry)
Hose length 1400mm
Length of connection cable 2000mm
Supply voltage See data plate on back of machine
Rated load See data plate on back of machine
Fuse rating See data plate on back of machine
Test certifications awarded See data plate on back of machine
LEDs Class 1
Designation of refrigerant R134a
Refrigerant quantity 0.61kg
Refrigerant global warming potential 1430kg CO
2
e
Appliance global warming potential 872kg CO
2
e
Max. floor load during operation 925N
Product safety standard EN50570, EN60335
A-rated sound emissions L
pA
in accord-
ance with ENISO11204/11203
<70dBre20μPa

Miele PDR 507 HP Marine Specifications

General

Brand	Miele
Model	PDR 507 HP Marine
Category	Dryer
Language	English
