Miele PG 8061 User Manual

Technical details
119
Height 32 5/16" (820mm) adjustable
+ 2 1/4" (60mm)
Height with cover 32 7/8" (835mm) adjustable
+ 2 1/4" (60mm)
Width 23 1/2" (598mm)
Depth
with door open
23 1/2" (600mm)
47 1/4" (1,200mm)
Weight (net) 154 lbs (70kg)
Voltage, rated load, fuse rating See data plate
Power cord Approx. 5' 6" (1.7m)
Water temperature:
Cold water connection
Hot water connection
Max. 68°F (20°C)
Max. 149°F (65°C)
Static water pressure Max. 145 psi (1000kPa) overpressure
Recommended flow pressure:
Cold and hot water connection
Water connection for steam condenser
29 psi (200kPa) overpressure
14.5 psi (100kPa) overpressure
Minimum flow pressure:
Cold water connection
Hot water connection
14.5 psi (100kPa) overpressure
5.8 psi (40kPa) overpressure
Drain hose height Min. 1' (0.3m), max. 3' 3" (1.0m)
Drain hose length Max. 13' 1" (4.0m)
Ambient temperature 40 - 104°F (5 - 40°C)
Relative humidity
Maximum
Linearly decreasing to
80% for temperatures up to 88°F (31°C)
50% temperatures up to 104°F (40°C)
Altitude above sea level Up to 6,561 ft (2,000m)*
Inlet hoses Approx. 5' 7" (1.7m)
Drain hose Approx. 4' 9" (1.5m)
Noise emission values
Sound power in LwA
Sound pressure in LpA
Undercounter installation with wooden trim
in front of base, Short program
57dB (A)
45dB (A)
Certification marks CSA approval, NSF
CE mark Machinery directive 2006/42/EC
Manufacturer's address Miele & Cie. KG, Carl-Miele-Straße 29,
33332 Gütersloh, Germany
* For installation at altitudes above 6,561 ft (2,000m), the boiling point of the wash water will be lower. In this case, the
dishwasher must be modified by Miele Service.
