Operation
46
DOS module
In addition to the internal dispensing systems, up to two additional
external dispensing systems (DOS modules) can be connected for
dispensing liquid process chemicals.
For more information on Miele DOS modules, please contact your
Miele dealer or Miele Service.
Siphon markings
Liquid process chemicals from external containers are supplied by
siphons. The siphons are color-coded to help ensure proper dispens-
ing.
Miele uses and recommends the following colors:
Blue: for detergent
Red: for rinse aid
For cleaning specific types of soiling, and for information on the best
detergents and additives to use for liquid dispensing, please contact
Miele Service.
Connecting DOS
modules
The DOS module comes with a separate installation manual.
Power supply connection for DOS1, detergent.
Power supply connection for DOS4, rinse aid.
Connections for dispensing hoses.
Before installing the DOS module, compare the connection data
(voltage and frequency) on the module's data plate with the infor-
mation on the data plate of your dishwasher. If the information
does not match, the module may become damaged. When in
doubt, consult an electrician.
Connect the module to the electrical supply.
To connect a dispensing hose, release the hose clip on a free con-
nector and remove the safety cap.
Push the dispensing hose onto the connector and secure it with a
hose clip.
