Technical data
105
Height 850 mm
Width 596 mm
Depth 637 mm
Depth with door open 1055 mm
Height for building under 820 (+8/-2) mm
Width for building under 600 mm
Weight approx. 98 kg
Capacity, washing
Capacity, drying
7.0 kg dry laundry
4.0 kg dry laundry
Voltage See data plate
Connected load See data plate
Fuse rating See data plate
Consumption data See "Consumption data"
Minimum flow pressure 100 kPa (1 bar)
Maximum flow pressure 1000 kPa (10 bar)
Inlet hose length 1.55 m
Drain hose length 1.50 m
Mains connection cable length 2.00 m
Delivery head max. 1.00 m
Maximum drainage length 5.00 m
LEDs Class 1
Test certificates awarded See data plate
