Milton Roy GM Series User Manual

24
Item
Number
Description Part Number Qty.
10
Pump Housing (IEC 71 Motor) S61021 1
Pump Housing (NEMA 56C Motor) 61345 1
60 Connecting Rod S70003 1
70 Oil Seal 35330 1
342
Worm Assembly, 8:1, 180SPM, IEC71 H60630 1
Worm Assembly, 8:1, 180SPM, NEMA 56C H60635 1
Worm Assembly, 10:1, 173SPM/144SPM, IEC71 H60631 1
Worm Assembly, 10:1, 173SPM/144SPM, NEMA 56C H60636 1
Worm Assembly, 14:1, 124SPM/103SPM, IEC71 H60634 1
Worm Assembly, 14:1, 124SPM/103SPM, NEMA 56C H60639 1
Worm Assembly, 20:1, 86SPM/72SPM, IEC71 H60632 1
Worm Assembly, 20:1, 86SPM/72SPM, NEMA56C H60637 1
Worm Assembly, 40:1, 43SPM/36SPM, IEC71 H60633 1
Worm Assembly, 40:1, 43SPM/36SPM, NEMA 56C H60638 1
360 Set Screw, M8 x 12 S61122 1
370 Vent H60724 1
400
Motor Mounting Bolts S4350038522 4
Motor Mounting Bolts S4050018119 4
410
Motor Mounting Washer
（
IEC Motors
：
Spring Lockwasher
）
S4340009002 4
Motor Mounting Washer
（
NEMA 56C Motors
：
Spring Lockwasher
）
N/A 4
Lubricating Oil
（
800ml
）
H69007 1
Nameplate N/A 1
Note:
1. Replacement of worm (342), only as assembly of item Worm (342), retaining ring (150), bearing (340),
worm coupling (346) and pin (347).
5.1 PARTS LIST FOR GM DRIVE SIDE VIEW (REFERRING TO FIGURE 5-1)
