Milton Roy GM Series User Manual

45
5.13 PARTS LIST FOR GM0090~GM0500 PVC & MIXED LIQUID END (REFERRING TO FIG-
URE 5-13 & 5-14)
Item
Number
Description Material Part Number Qty.
Suction/Discharge Valve Assembly (PVC LE , Code Q,
DN 15 ) (Before 2019.11
）
- H60615 2
Suction/Discharge Valve Assembly (PVC LE , NPT1/2” )
(Before 2019.11)
- H60624
2
Suction/Discharge Valve Assembly (PVC LE , NPT1/2” )
(After 2019.11)
- P300125099 2
Description ‘Suction/Discharge Valve Assembly (PVC
LE , Code Q, DN 15 ) (After 2019.11)
- P300121099 2
Suction/Discharge Valve Assembly (Mixed LE) - H60616 2
047 Tubing Connector PE S0470096073N 1
072A
Spacer(After 2008 New Spring Structure) ASTM 2017 H60673 1
Spacer LE03/04 (35330 OIL SEAL) (Before 2008 Old
Spring Structure)
ASTM 2017 H70096 1
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC ( After 2019.11)
PVDF/PTFE P300116099 1
098B
098A
098C
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC (2008 ~2019.11 New Spring
Structure)
PP/PTFE 3050976111N
1
098B
098A
098C
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC (Before 2008 Old Spring
Structure)
PP/PTFE 3050976110N
1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC( After 2019.11)
PVDF/PTFE P300117099 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC (2008-2019.11 New Spring
Structure)
PP/PTFE 3050976091N 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC (Before 2008 Old Spring
Structure)
PP/PTFE 3050976090N 1
098B
098A
098C
370
Head (GM0090~GM0240) PVC S60033 1
Head (GM0330~GM0500) PVC H60748 1
