Milton Roy GM Series User Manual

51
5.16 PARTS LIST FOR GM0090~GM0500 HIGH VISCOSITY LIQUID END (REFERRING TO
FIGURE 5-13 & 5-16)
Item Num-
ber
Description Material Part Number Qty.
Suction Check Valve Assembly - H60621 1
Discharge Check Valve Assembly - H60620 1
047 Tubing Connector - S0470096073N 1
072A
Spacer(After2008 New Spring Structure) ASTM 2017 H60673 1
Spacer LE03/04 (35330 OIL SEAL) (Before 2008
Old Spring Structure)
ASTM 2017 H70096 1
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC (After 2019.11)
PVDF/PTFE P300116099 1
098B
098A
098C
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC (2008 -2019.11New
SpringStructure)
PP/PTFE 3050976111N 1
098B
098A
098C
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PP/PVC (Before 2008 Old
Spring Structure)
PP/PTFE 3050976110N 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC(After 2019.11)
PVDF/PTFE P300117099 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC (2008 -2019.11New
SpringStructure)
PP/PTFE 3050976091N 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PP/PVC (Before 2008 Old
Spring Structure)
PP/PTFE 3050976090N 1
098B
098A
098C
370
Head, (GM0090-GM0240) PVC S60033 1
Head, (GM0330-GM0500) PVC H60748 1
434 Washer - S4340005085N 6
435 Bolt - H65281 6
435A Nut - S4350000043N 6
435B Screw - S4350047395N 4
700A
Diaphragm Support Ring (GM0090~GM0240) PVC H60671 1
Diaphragm Support Ring (GM0330~GM0500) PVC H60672 1
