42
5.12 PARTS LIST FOR GM0025~GM0050 HIGH VISCOSITY LIQUID END TUBING CONNECTION
(REFERRING TO FIGURE 5-12)
Notes:
1. Replacement of Suction/Discharge Check Valve Assembly, only as assembly of item Nut (104), Ball Check
(250), Spring (255), Washer (703), Adaptor (704), Seat (707), Threaded Connection (708).
2. Replacement of Diaphragm Assembly (098), only as assembly of item Diaphragm (098), Plate (098A),
Diaphragm (701), O-Ring (438), Screw (435A)
Item
Number
Description Material Part Number Qty.
Suction Check Valve Assembly PVC H60607 1
Discharge Check Valve Assembly PVC H60608 1
098 Diaphragm Assembly PVDF/PTFE H60610 1
103 Screw - S10340 4
700F Screw - S70054 4
351 Spacer - S35116 1
435 Screw A2-70 S4350016075N 1
370 Head PVC 35031 1
Injection Valve - 77031 1
Tubing,15
×
23 PVC 70122-2M 1
Tubing,9.52
×
12.7 PE 10142-3M 1
Threaded Connection, 1/2” NPT - 25650 1
Collar - 4340029020N 2
To Next Page
