47
5.14 PARTS LIST FOR GM0090~GM0500 PVDF LIQUID END (REFERRING TO FIGURE 5-13 & 5-14)
Note:
1. Replacement of suction/discharge check valve, only as assembly of item check valve body (003), seat (024),
ball check (437), O-ring (438), threaded connector.
Item
Number
Description Material Part Number Qty.
Suction/Discharge Valve Assembly H60673 2
047 Tubing Connector - S0470096073N 1
072A
Spacer(After2008 New Spring Structure) ASTM 2017 H60673 1
Spacer LE03/04 (35330 OIL SEAL) (Before 2008 Old
Spring Structure)
ASTM 2017 H70096 1
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PVDF (After2008 New Spring
Structure)
PVDF /PTFE 3050976131N
1
098B
098A
098C
098
Diaphragm Assembly (D.82), PTFE
GM0090-GM0240 PVDF (Before 2008 Old Spring
Structure)
PVDF /PTFE 3050976130N
1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PVDF (After2008 New Spring
Structure)
PVDF /PTFE 3050976231N 1
098B
098A
098C
098
Diaphragm Assembly (D.93), PTFE
GM0330-GM0500 PVDF(Before 2008 Old Spring
Structure)
PVDF /PTFE 3050976230N 1
098B
098A
098C
370
Head (GM0090~GM0240) PVDF S0210780078N 1
Head (GM0330~GM0500) PVDF H60650 1
434 Washer A140 S4340005085N 6
435 Bolt A2-70 H65281 6
435A Nut A2-70 S4350000043N 6
435B Screw A2-70 S4350047395N 4
700A
Diaphragm Support Ring (GM0090~GM0240) PVC H60671 1
Diaphragm Support Ring (GM0330~GM0500) PVC H60672 1
700B Washer - S70029 1
700C
Spring, (After2008 New Spring Structure) - 08001870017N
1
Spring, LE03/04 (Before 2008 Old Spring Structure) S70081
701
Cross Piece (After2008 New Spring Structure)
ASTM2071
S01903850071N
1
Cross Piece (Before 2008 Old Spring Structure) H60500
To Next Page
