Mindray CAL 8000 User Manual

Understanding the CAL 8000 System
2-2
2.2 System Configuration
The number of track modules in the system is determined by the number of Analyzers and
SM&S connected in the auto sample processing line, 6 track modules can be configured at
most to transmit and distribute samples for 6 external devices connected.
Names of Assemblies
Models Supported
Function Introduction
Auto Hematology
Analyzer
(Analyzer)
BC-6800, BC-6600
Analyzing blood or body fluid samples,
providing sample cells analysis results
Auto Slide Maker &
Stainer
(SM&S)
SC-120
Making sample slides
Auto Sample Processing
System
CAL 8000
Forming a processing line together with
the Analyzer and SM&S to transmit,
distribute and analyze in-vitro diagnostic
samples, and manage samples and data
after the analysis.
The Auto Sample Processing System has 8 configurations currently (based on the number of
the analyzer and Stainer): For example, “1 x Analyzer” means the track module supports the
connection to one Analyzer, “1 x Stainer” means the track module supports the connection to
one Stainer.
Configuration
loading
module
Unloading
module
Nonterminal
analyzer track
module
Nonterminal
Stainer track
module
Terminal
track module
Configuration 1
1
1
1
0
1 x Analyzer
Configuration 2
1
1
2
0
1 x Analyzer
Configuration 3
1
1
3
0
1 x Analyzer
Configuration 4
1
1
1
0
1 x Stainer
Configuration 5
1
1
2
0
1 x Stainer
Configuration 6
1
1
3
0
1 x Stainer
Configuration 7
1
1
4
0
1 x Stainer
Configuration 8
1
1
4
1
1 x Stainer
