P/N: H-046-005847-00 Rev 3.0
21
Passport
®
Quick Reference Guide
To view and print an alarm event on a patient on the Passport 8 or Passport 12
bedside monitor:
a. Select Review >> (quick key) or from Main Menu (quick key)
b. Select Events tab
c. Scroll and select event
d. Select Details to view the 8, 16, or 32-second event*
e. Select
•Record to print to the integrated recorder
•Print to print to the DPM Central Station/independent printer
f. Select Main Menu (quick key) or to return to the main display
* Alarm Recording length configurable
Note: The waveforms printed are determined by the Recorder and Print
Setup menus on the Passport 8 or Passport 12 bedside monitor.
DPM Central Station Interface: Event storage and printing length on the
Passport 8 or Passport 12 bedside monitor and DPM Central Station are
independent.
Panorama Central Station Interface: Event storage and printing length on the
Passport 8 or Passport 12 bedside monitor and Panorama Central Station are
independent.
Full Disclosure
The Passport 8 or Passport 12 bedside monitors have the ability to store
configured waveforms and associated numeric information for up to 48 hours.
To adjust waveforms to be stored on a patient:
a. Select Review>> (quick key) or from Main Menu (quick key)
b. Select Full Disclosure tab
c. Select Save Waves >>
d. A in the waveform box indicates waveform is selected
e. Select Confirm to return to Full Disclosure tab
f. Select Main Menu (quick key) or to return to the main display
