P/N: H-046-005847-00 Rev 3.0
22
Passport
®
Quick Reference Guide
To record waveforms stored on a patient:
a. Select Review >> (quick key) or from Main Menu (quick key)
Select Full Disclosure tab
b. Select Record to record the first three saved waveforms
DPM Central Station Interface: Waveform Review (Disclosure) storage and
printing on the Passport 8 or Passport 12 bedside monitor and DPM Central
Station are independent.
Panorama Central Station Interface: Full disclosure storage and printing on
the Passport 8 or Passport 12 bedside monitor and Panorama Central Station
are independent.
VOLUMES
The alarm volume, key volume, and QRS volume can be adjusted on the
Passport 8 or Passport 12 bedside monitors.
To adjust the alarm volume on the Passport 8 or Passport 12 bedside monitor:
a. Select Volume (quick key) or select Others Tab in Alarm Setup
(quick key)
b. Select Alm Vol
c. Select volume ranging from X*-10 (0=Off 10=Max)
d. Select Main Menu (quick key) or to return to the main display
* The minimum volume range (X) is predetermined during installation.
Key Volume
To adjust the key volume on the Passport 8 or Passport 12 bedside monitor:
a. Select Volume (quick key)
b. Select Key Vol
c. Select volume ranging from 0-10 (0=Off 10=Max)
d. Select Main Menu (quick key) or to return to the main display
To Next Page
