5-40 Image Optimization
Operation
Adjust through the [Display Format] item in the menu.
5.11.1.3 Exit
 In Free Xros M mode, tap [Free Xros M] or [B] to exit.
5.12 iScape View (Real-time Panoramic
Imaging)
The iScape panoramic imaging feature extends your field of view by piecing together multiple B
images into a single, extended B image. Use this feature, for example, to view a complete hand or
thyroid.
When scanning, move the probe linearly and acquire a series of B images. The system pieces
these images together into a single, extended B image in real time. The system also supports out-
and-back image piecing.
After obtaining the extended image, you can rotate it, move it linearly, magnify it, add comments or
body marks, or perform measurements on the extended image.
CAUTION:
iScape panoramic imaging constructs an extended image from
individual image frames. The quality of the resulting image is
user-dependent and requires operator skill and additional
practice to become fully proficient. Therefore, the
measurement results can be inaccurate. Exercise caution
when you perform measurements in iScape mode. A smooth
and even speed will help produce optimal image results.
iScape images are provided for reference only, not for
confirming diagnoses.
 iScape is an option.
 Displaying the biopsy guideline is not allowed in iScape mode.
5.12.1 Basic Procedures for iScape Imaging
To perform iScape imaging:
1. Connect an appropriate iScape-compatible probe. Make sure there is enough coupling gel along
the scan path.
2. Tap [iScape].
3. Optimize the B mode image.
In the acquisition preparation status, tap [B] on the imaging parameter menu to optimize the B
mode image. Perform measurement or add comments/body marks to the image if necessary.
4. Image acquisition.
Tap [Capture] on the imaging parameter menu, and then tap [Start Capture] or [Update] to begin
the acquisition.
Tap [Stop Capture] to stop the acquisition. The system enters image viewing status when the
acquisition is completed. You can perform operations such as parameter adjusting.
5. Exit iScape.
Tap [Unfreeze], [Update] or [ReCapture] to return to B mode.
