7-2 Measurement
7.2 General Measurements
There are measurements for B/B + Color/B + Power mode, M mode and Doppler (PW/CW) mode.
Measurement
Tools
Function
Distance
Measures the distance between two points of interest.
Depth
Measures the distance between the probe surface and the probing point
along the ultrasound beam.
Angle
Measures the angle between two intersecting planes.
Ellipse
Fix a closed ellipse region by two axes perpendicular to each other and
calculate the area of the closed region.
Trace
Fix a closed region by trace manually and calculate the area of the closed
region.
Smart Trace
Measures the lengths of major axis and minor axis, area and circumference
of a closed region on the image semi-automatically
Volume
Measures the volume of a target.
Distance Ratio
Measures the lengths of any two lines and calculates the ratio.
Area Ratio
Measures the areas of any two regions and calculates the ratio.
Time
Measures the time interval between any two points.
Slope
Measures the distance and time between two points and calculates the
slope.
HR
Measures the time of n (n≤8) cardiac cycles and calculates the heart rate in
M mode images.
Velocity
Calculates the average velocity by measuring the distance and time
between two points.
D Trace
On PW mode images, one or several Doppler waveforms are traced to
obtain the speed and PG, etc.
D Trace (Car)
On PW mode images in cardiology, one or several Doppler waveforms are
traced to obtain the speed and PG, etc.
PS/ED
Velocity and PG between two peaks on the spectrum are measured to
calculate the RI (resistance index) and PS/ED (peak systolic/end diastolic).
