Peripheral devices
12
INSTALLATION AND WIRING
2.1 Peripheral devices
2.1.1 Inverter and peripheral devices
• For operating two inverters in parallel
(c) Three-phase AC
power supply
接地
接地
接地
接地
One circuit breaker and one magnetic contactor per converter unit
One circuit breaker and one magnetic contactor in total in a system
To the master converter unit
To the slave converter unit
(d) Molded case circuit
breaker (MCCB) or fuse
(e) Magnetic
contactor
(MC)
(f) Noise filter
(g) Noise filter
(g) Noise filter
R/L1
S/L2
T/L3
N/-
P/+
N/-
P/+
U
V
W
(b) Converter unit
(FR-CC2-P)
(b) Converter unit
(FR-CC2-P)
R/L1
S/L2
T/L3
N/-
P/+
N/-
P/+
U
V
W
(a) Inverter
(FR-A802-P)
Earth (Ground)
(h) Induction
motor
Earth (Ground)
Earth (Ground)
Earth (Ground)
(a) Inverter
(FR-A802-P)
(c) Three-phase AC
power supply
(d) Molded case circuit
breaker (MCCB) or fuse
(e) Magnetic
contactor
(MC)
(f) Noise filter
: Install these options as required.
Earth (Ground)
