OCH610G
3-4. ELECTRICAL PARTS SPECIFICATIONS
Service Ref.
Parts name
Symbol
PLFY-EP06NEMU-E
PLFY-EP08NEMU-E
PLFY-EP12NEMU-E
PLFY-EP15NEMU-E PLFY-EP18NEMU-E
PLFY-EP18NEMU-E1
PLFY-EP24NEMU-E
PLFY-EP30NEMU-E
PLFY-EP36NEMU-E
PLFY-EP48NEMU-E
Room temperature
thermistor
TH21
5HVLVWDQFH)N)N)N)N)N)N
Liquid pipe thermistor TH22 5HVLVWDQFH)N)N)N)N)N)N
Gas pipe thermistor TH23 5HVLVWDQFH)N)N)N)N)N)N
Fuse
(Indoor controller board)
FUSE UL 6.3A 250 V AC
Fan motor MF 8-pole OUTPUT 50W
8-pole OUTPUT, 120W
Vane motor MV
MSBPC20M04
9'&SKDVH
Drain pump DP
PLD-12230ME-1
INPUT 12/10.8W 24
R
/Hr
'UDLQÀRDWVZLWFK FS Open/short detection
Linear expansion valve LEV
12 V DC Stepping motor drive port dimension ø3.2 (0–2000pulse)
EDM-40YGME
12 V DC Stepping motor drive
port dimension
ø 5.2 (0–2000pulse)
EDM-80YGME
Power supply terminal
block
TB2 (L1, L2, GR) 330 V, 30 A
Transmission terminal
block
TB5 (M1, M2, S) 250 V, 20 A
MA remote controller
terminal block
TB15 (1, 2) 250 V, 10 A

Mitsubishi Electric City Multi Series Specifications

General

Refrigerant	R410A
Control	Centralized control, individual control
Indoor Unit Types	Ceiling Cassette, Ceiling Suspended, Wall Mounted
Power Source	Electric
Piping Length	Up to 1000m total piping length (depending on the model)
Height Difference	Up to 50m
