132
10 TROUBLESHOOTING
10.6 How to Check Error Codes
10.6 How to Check Error Codes
When the data link is established between the safety remote I/O module and the master station, errors can be checked on the
engineering tool.
• Page 132 Checking with CC-Link IE TSN/CC-Link IE Field diagnostics
• Page 134 Checking with "Command Execution of Device Station"
• Page 136 Checking error codes and warning codes
When the user authentication function of the CPU module is enabled, perform the logon of the user
authentication function in advance. For the user authentication function, refer to the following.
Page 109 User Authentication Function
Checking with CC-Link IE TSN/CC-Link IE Field diagnostics
1. To check an error history, select a relevant module from the "CC-Link IE TSN/CC-Link IE Field Diagnostics" window.
To Next Page
